RacingLine Rear Body Brace MQB

WHAT DOES THE BODY BRACE DO?

Modern cars like the MQB & MQB EVO platform run a pretty stiff laser-welded bodyshell. Up front, the chassis is very rigid between the suspension tops, but at the rear there is much more chassis flex which negatively affects vehicle handling in hard use, especially with stiff suspension. That's why the Clubsport S Golf gets a factory rear brace.



The new RacingLine Rear Body Brace solves this issue by locking the crucial hard points together.

The RacingLine Rear Body Brace uses solid billet aluminium mounts secured into beautiful, ultra-stiff carbon fibre link bars drastically stiffening the rear of the chassis.

By reinforcing and tying the rear strut towers together, the brace helps to maintain proper suspension geometry under heavy cornering loads. Remove the bodyshell flex, and the suspension geometry can work as it was designed to do.

Despite the added stiffness, this improved handling performance comes without sacrificing any ride quality or introducing any additional noise, vibration, or harshness into the cabin.

The clever design means that installation is simple, using existing body mounting points with no drilling and no removal of trim required, and is completely reversible.

Compatible with rear seats up or down (or removed altogether). The full interior can be maintained even with the installation of the Rear Body Brace.

Golf R MQB Rear Body Brace

REAR BODY BRACE FOR MQB GOLF R 7 & 7.5, GOLF GTI / AUDI A3, S3, RS3 / SEAT LEON / OCTAVIA  & MORE.

MQB REAR
BODY BRACE

FOR MANY MQB CARS - GOLF 7/8, LEON III & IV, A3/S3/RS3 8V & 8Y, OCTAVIA III & IV

Want to sharpen up your Golf 7 & 7.5 / Audi A3, S3, RS3 / Leon / Octavia handling responses? Our beautiful billet and carbon Rear Body Brace reinforces the bodyshell at its weakest point for a more precise and pleasurable drive.

Carbon Audi A3, S3, RS3 Rear Body Brace

GLOSS BLACK & CARBON

GOLF  / LEON / OCTAVIA

VWR81G700

Audi A3 / S3 / RS3

VWR8130S3

VWR8130S3-SEDAN

Audi S3 RS3 rear body brace

PRECISION ENGINEERED FOR PERFECT PERFORMANCE.

All mounts are CNC 5-axis machined from solid billet

Rear body brace for VW

Aerospace-grade T6-6061 Aluminium used throughout

Top mounts located into rear seat mounts

Lower mounts lock into cargo tie-downs

FEA-developed triangulation design maximises stiffness whilst keeping weight down

3K twill weave carbon fibre ultra-stiff link bars

RacingLine Carbon Rear Body Brace
CONFIRMED APPLICATIONS
VOLKSWAGEN, SEAT/CUPRA, SKODA: MQB & MQB 'EVO'
VWR81G700

GOLF 7 & 7.5    3 DOOR

GOLF 7 & 7.5    5 DOOR

GOLF 7 & 7.5    WAGON/VARIANT *4Motion wagon models only

GOLF 8    5 DOOR

SEAT Leon III    3 DOOR

SEAT Leon III    5 DOOR

SEAT Leon III    ST WAGON/VARIANT *4Motion wagon models only

SEAT Leon IV    5 DOOR

Skoda Octavia III    5 DOOR

Skoda Octavia III   WAGON

Skoda Octavia IV    5 DOOR

NOTE: Leon & Octavia models require the rear boot carpet to be cut in order to mount the rear brace. Template and instructions for download below.

CONFIRMED APPLICATIONS
AUDI A3 / S3/ RS3: MQB & MQB 'EVO'

VWR8130S3

Audi 8V A3 / S3 / RS3   3 & 5 DOOR SPORTBACK

Audi 8Y RS3  5 DOOR SPORTBACK

(note: not for 4 door sedan models)

Audi A3 2013-2020 8V / 3 & 5 door

Audi S3 2013-2020 8V / 3 & 5 door

Audi RS3 2015-2020 8V / 5 door

Audi RS3 2021+ 8Y / 5 door

VWR8130S3-SEDAN

Audi 8V A3 / S3 / RS3  4 DOOR SEDAN/SALOON

Audi 8Y A3 / S3 / RS3  4 DOOR SEDAN/SALOON

(note: AWD QUATTRO models only

Audi A3 2013-2020 8V / 4 door sedan

Audi S3 2013-2020 8V / 4 door sedan

Audi RS3 2015-2020 8V / 4 door sedan

Audi RS3 2021+ 8Y / 4 door sedan

NEW!

Audi A3, S3, RS3 Carbon Rear Body Brace

LOW PROFILE

Thin, low-profile design means minimum impact on boot space and no effect on rear seat operation.

Golf mk7 Performance Accessories

EASY INSTALL/REMOVE

Clever design means fitting is quick and simple. Completely reversible without trace for removal.

Seat Leon Cupra performance Rear Body Brace

NO DRILLING

No cutting, no drilling needed. By cleverly re-using the strongest parts of the body, there's no need to modify.

Carbon fiber rear body bracing

PRACTICAL

Compatible with rear seats up or down, and we've even added in the luggage tie-downs into the mounting points.

MQB VW Audi Seat Skoda body brace

LIGHTWEIGHT

A ruthless approach to weight-saving. Billet aluminium mounting brackets bonded to ultra stiff 3K twill carbon link bars.

MQB Rear suspension Brace

ADJUSTABLE

Every mass-produced car body has small differences in dimensions. The brace is tensioned after fitment for ultra-tight alignment to your car.

VW Golf performance Rear Brace
LEON & OCTAVIA MODELS

These two models require the rear boot carpet to be trimmed in order to mount the rear brace.

Alongside the fitting instructions, please download cutting templates for either model below:

rear brace Leon Octavia
rear strut brace bar for VW Golf
Rear Strut Brace for Audi RS3, S3, A3
WHAT'S IN THE KIT?
VW Rear Strut Brace for Golf R, Golf GTI

4x Mounting brackets

1x Tensioning block

1x Carbon Cross Bar

2x Carbon Brace Bar

All required fitting hardware

Body Brace for VW, Audi, Seat, Skoda
IMPORTANT:
Not to be used as a mounting point for seatbelts or race harnesses.
