TAKE CONTROL

OF YOUR OIL.

If you're going to take your MQB car on track, you really need our Oil Management Kit. Without it, you'll risk oil starvation.

Simple as that.

PROTECTING YOUR ENGINE'S LIFEBLOOD.

HOW

IT WORKS.

Not all catch tank kits are equal.

Designed with a built in engine baffle

plate, our system is uniquely designed to aid

engine oil control, as well as catching unwanted oil and water vapour.

The 2.0 TSI EA888.3 retains oil in the engine under excessive braking G-forces. Oil pools at the front of the engine, leading to smoke clouds and ultimately oil starvation.

3 way baffled catch tank to effectively

collect excess moisture and oil vapour.

Keeps your intercooler and inlet tracts clear of oil build-up and provides clean airflow through the inlet manifold.

DIRECT PCV REPLACEMENT

Our catch tank kit is supplied complete with a replacement PCV plate offering easy installation.

210 SERIES BRAIDED HOSE

Our oil lines feature an attractive outer nylon braid strengthened by a stainless steel inner weave for maximum resilience.



SUPERIOR BAFFLE SYSTEM

A built in baffle plate prevents oil surging to the cylinder head and making its way into the intake - or worse, starving the engine.

CATCH TANK

Not just a tank, but a three way inner division ensures separation of moisture and oil.

PRECISION MACHINED

Precision machined components utilising

the latest 5 Axis CNC machines.

POLISHED SWIVEL FITTINGS

Racingline fittings are all hand polished before anodising for the ultimate finish and limits the chances of "spanner rash"



THE EA888.3

OIL SURGE ISSUE

Regular track drivers have discovered that not all catch tank kits are equal.

The most important and unique aspect of our Oil Management System is that it offers a proper solution to oil starvation under high-G braking. So, push your car hard on track, with track-tyres and uprated brakes and this is something that you really need to be aware of.

It's no surprise that we share this exact same oil management design with Volkswagen Motorsport, Audi Sport and Cupra for the TCR race cars. Our clever baffled PCV block forces the oil back to the sump under heavy braking to fix this problem once and for all.



Don't go on track without it!

WHAT HAPPENS

WITHOUT IT.....

PRECISION ENGINEERED FOR PERFECT PERFORMANCE.

AN-10 male fitting for main breather line.

Removable baffle plate for easy maintenance

Sealing gasket against the PCV replacement plate.

Meticulously machined

with the latest CNC technology.

racingline oil catch can, racingline oil management kit, golf 7 r oil catch can, golf 7 gti oil catch can, audi s3 oil catch can, seat leon oil catch can

CATCH TANK FEATURES.

Our catch tanks are machine welded for the

best possible finish before being coated in our distinct "crinkle black" powder coat. All this is to ensure a Racingline catch tank stands the test of time and retains its looks.

Easy level measure with our built in dipstick.

Drain Plug at the base of the tank for easy

disposal of excess fluids.

Our catch tank locates on the side of your engine mount and utilises the original chassis bolt, retaining a true OE appearance.

Our OEM   Performance Software is simply the most effective modification you can make to the 2.0 TSI engine, especially when used alongside our performance hardware.

That's what makes the OEM   difference.

+

+

SOFTWARE DESIGNED FROM THE GROUND UP.

Give your vehicle the OEM   treatment.
+

CHOOSE YOUR MODEL

TO SEE YOUR SOFTWARE

2019 VW Golf R Mk7.5 - Rotiform DTM Forg
racingline oil catch can, racingline oil management kit, golf 7 r oil catch can, golf 7 gti oil catch can, audi s3 oil catch can, seat leon oil catch can
SO WHAT'S IN THE KIT?

Replacement PCV breather plate

Baffled breather cap

Breather hose from cap to catch tank

Baffled catch tank

Breather return hose from catch tank to inlet

Oil catch tank dipstick

Catch tank drain plug

PCV solenoid vent hose & adapter

Washer blanking plug (R Models only)

Fixing kit containing all required bolts, washers and rubber o-ring cord.

2019 VW Golf R Mk7.5 - Rotiform DTM Forg

YOU MAY

ALSO NEED

Own a Golf 7R or Audi S3 8V?

Golf 7R and some early Audi S3 models have a different windscreen washer bottle fitment to the other MQB cars.  The reservoir is located on the right of the vehicle - which is where your new Catch Can will be mounted. So our Remote Washer Refill kit must be fitted as well.

CONFIRMED APPLICATIONS

* For 2019 Golf GTI only a new evaporation canister which obstructs the catch can fitment.

You will need to purchase Volkswagen part 5Q0133366K to allow fitment.

OTHER PRODUCTS TO SET YOUR PULSE RACING.

REMOTE WASHER REFILL

To fit our Oil Management Kit on Golf 7R and Audi S3 models, you will also need this Remote Washer Refill Kit.



STAGE 3 TURBO KIT

Our OEM+ Stage 3 upgrade offers a complete, turn-key package that is entirely usable on a daily-driven car yet offers devastating performance just one squeeze of the throttle away.

PERFORMANCE INTERCOOLER

Our giant sized, high efficiency front mounted intercooler is an essential upgrade to keep intake temperatures low - and keep power levels high.
